OMM8 / BMM8 J 129 Series OMM Hydraulic Motor Lawn Mower Supply , High Speed Hydraulic Winch Motor

Dongguan Blince Machinery & Electronics Co., Ltd.
Contact Now

OMM8 / BMM8 J 129 Series OMM Hydraulic Motor Lawn Mower Supply , High Speed Hydraulic Winch Motor

  • 1
  • 2

Brand Name : BLINCE

Model Number : OMM 8

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : Western Union, T/T, L/C

Supply Ability : 3000pcs/month

Delivery Time : 5-10days

Packaging Details : 1.sale packing contians carton or wood case 2.interior packing is high quality film

Certification : ISO9001:2008

Type : OMM Hydraulic motor

Max Speed : Cont 400-1950rpm

Pressure : 7-10Mpa

Torque : Cont 11-46 n.m

Flow : Cont 16-20 L/min

Appearance : Phosphating & Painting

Displacement range : 8.2 ~50.3cc/rev

Output power : cont 1.8~2.4kw

Motor flange : Circle / diamond flange

Contact Now

OMM8 / BMM8 J 129 Series OMM Hydraulic Motor Lawn Mower Supply , High Speed Hydraulic Winch Motor

OMM series motor are small volume,economical type,which is designed with shaft distritubion flow, which adapt the Gerotor gear set design and provide compact volume,high power and low weight, widely used in agriculture, forestry, plastics, machine tools and mine machines, etc.

Advantages:

1. small volume to easy installation

2. high speed max 1950 rpm
3. freely disassemble leakage

4. applicated in sweeper machine / injection molding machine / winch / lawn mower / mini garden tractors/ wheat harvest machine / fish boat/ mini crawler tractor / winch machine / convery equipment/ road line maker /etc.

Features
Displacement 8.2 - 50.3 cm3/rev
Maximum speed range 400 - 1950 rpm
Maximum pressure from 70 bar to 100 bar (continuous)
Maximum torque from 11N.m to 46N.m

Blince OMM equivalent with Danfoss OMM series and Char-lynn J 129 series
Type

OMM

8

OMM

12.5

OMM

20

OMM

32

OMM

40

OMM

50

Geometric displacement 8.2 12.9 19.9 31.6 39.8 50.3
Max.speed (rpm) cont. 1950 1550 1000 630 500 400
int. 2450 1940 1250 800 630 500
Max.torque(N.m) cont. 11 16 25 40 45 46
int. 15 23 35 57 70 88
Max.output(KW) cont. 1.8 2.4 2.4 2.4 2.2 1.8
Int. 2.6 3.2 3.2 3.2 3.2 3.2

Max.pressure

Drop (Mpa)

cont. 10 10 10 10 9 7
int. 14 14 14 14 14 14
Max.flow(L/min) cont. 16 20 20 20 20 20
int. 20 25 25 25 25 25
Weight(kg) 1.9 2 2.1 2.2 2.3 2.4

OMM8 / BMM8 J 129 Series OMM Hydraulic Motor Lawn Mower Supply , High Speed Hydraulic Winch Motor OMM8 / BMM8 J 129 Series OMM Hydraulic Motor Lawn Mower Supply , High Speed Hydraulic Winch Motor

OMM8 / BMM8 J 129 Series OMM Hydraulic Motor Lawn Mower Supply , High Speed Hydraulic Winch Motor

Please do not hesitate to contact us for further information, inquiries or orders.

Thank you for choosing Blince Hydraulic.
